32 millimeters has a relatively large printing width
Comparable high speed: 125 packets per minute
An economical solution suitable for low-speed applications
| Value | |
| Printer Mode | Intermittent and Continuous Motion |
| Print Pitch | 1 mm (0.039 in) |
| Maximum Ribbon Length | 600 m (1,968 ft) |
| Ribbon Width | 22 mm (0.87 in) and 33 mm (1.30 in) |
| Continuous Mode: | |
| Maximum Print Area (Width × Length) | 32 × 40 mm (1.26 × 1.57 in) |
| Maximum Print Speed | 500 mm/s (19.69 in/s) |
| Minimum Print Speed | 40 mm/s (1.57 in/s) |
| Intermittent Mode: | |
| Maximum Print Area (Width × Length) | 32 × 34 mm (1.26 × 1.34 in) |
| Maximum Print Speed | 200 mm/s (7.87 in/s) |
| Minimum Print Speed | 50 mm/s (1.97 in/s) |
| Barcode Printing | Logo only |
| Estimated Maximum Output (single line, continuous mode) | Approx. 125 packs/min |
| Standard User Interface | CLARiTY™ 114.78 mm SVGA Color Touch LCD |
| Standard Communications | RS232, USB Memory Stick |
Supports consistent high-quality printing and flexible coding:
300 dpi printing resolution ensures high-quality coding
Patented software-controlled ribbon driver can fully control ribbon movement and tension
Real-time variable data can handle various applications
Can print up to 32 mm (1.26 inches) wide codes at a speed of up to 125 packages per minute
Simple usability reduces manual operations and lowers error risks:
The intuitive CLARiTY™ 5.7-inch color touchscreen makes setup quick and easy, and can reduce errors
Automatically updates variable data and time fields without the need to spend time and effort changing the stamp
Compared to having to loop the ribbon around multiple obstacles through the printer, using the ribbon box makes ribbon replacement fast and convenient
Has uptime advantages, reduces downtime, and thus saves production time and funds:
Through highly reliable non-disengaging drivers, maintains consistent ribbon tension, avoiding machine downtime due to ribbon issues
Compatible with both intermittent and continuous printing functions in the same machine, preparing for future packaging equipment upgrades
600 meters (1,968 feet) of ribbon length and 1 mm (0.039 inches) printing spacing mean less ribbon replacement than mechanical imprint systems
The innovative ribbon-saving feature (cross-printing) can double ribbon utilization, save money and extend ribbon replacement cycles
The coding quality assurance function helps eliminate costly coding errors:
Advanced coding software can completely eliminate coding setup errors
CLARiSOFT® coding design software can avoid printing date errors, coding omissions and costly production rework
